M540072-01 Rev B 2-1
SECTION 2
INSTALLATION AND MAINTENANCE
2.1 INTRODUCTION
This section discusses the installation and removal procedures for the SLM-Series
AC/DC load module and the SLM four-module mainframe. The SLM-Series AC/DC
load module does not need any adjustment after plugging into the SLM mainframe.
Warning:
Only qualified personnel should do installation and removal.
2.2 INSPECTION
The SLM-Series AC/DC Electronic Load was carefully inspected before shipment. If
instrument damage has occurred during transport, please inform Xantrex sales and
service office or representative.
Unless the SLM mainframe and the SLM-Series AC/DC electronic load module were
purchased separately, the load module should be installed in the mainframe before
shipment from Xantrex. The SLM-Series AC/DC electronic load module operates in
the SLM mainframe for front panel, mainframe's 150 sets store/recall and remote
control feature.
2.2.1 Installation
1 Turn the SLM mainframe power OFF before inserting any load module, or
damage may occur to the plug-in module circuitry.
2. Align the upper and lower grooves of the mainframe with the upper and lower
guides of the selected compartment (Figure 2-1).
3. Push the module in and press firmly on the binding posts of the front panel to
seat the circuit board into the interconnecting jack.
4. Using a screwdriver, tighten the screw on the lower right corner of the SLM-
Series load module front panel.
5. DO NOT turn the mainframe power ON until after all of the electronic modules
are completely installed.
