M540073-01 Rev C 1-1
SECTION 1
FEATURES, FUNCTIONS,
AND SPECIFICATIONS
1.1 GENERAL DESCRIPTION
SLH-Series High Power, AC/DC Electronic Load is used to test the specification
characteristics of AC/DC high power suppliers and the service life characteristics of
batteries.
The load works with GPIB interface and front panel manual operation.
1.2 POWER CONTOURS
The power contours of the SLH-Series AC/DC Electronic Loads are shown in the
following figures.
0
250
500
0 2 4
Current (A)
Voltage (V)
300
10
2.4
Figure 1-1 SLH-500-4-1200 Electronic Load Power Curve
