Chapter 4: BIOS Setup
OPPC 1520T/1720T User Manual
If you selected RS422 or RS485 in the “Serial Port1 Frequency Mode”
and/or “Serial Port2 Frequency Mode” field, the “Serial Port1 Frequency
Select” and/or “Serial Port2 Frequency Select” field will appear prompt-
ing you to select the frequency setting. The options are 115200 bps and
921600 bps.
Serial Port2 Frequency Mode
This field is used to select the frequency mode of serial port 2. The op-
tions are RS232, RS422 and RS485.
Allows BIOS to select
Serial Port1 Base
Address.
BIOS SETUP UTILITY
← →
Select Screen
↑↓
Select Item
+-
Change Option
F1
General Help
F10 Save and Exit
ESC Exit
Configure ITE8783 Super IO Chipset
Serial Port1 Address
[3F8]
Serial Port1 IRQ
[3]
Serial Port1 Frequency Mode [RS232]
Serial Port2 Address
[2F8]
Serial Port2 IRQ
[4]
Serial Port2 Frequency Mode
[RS232]
Serial Port3 Address
[3E8]
Serial Port3 IRQ
[10]
Serial Port4 Address
[2E8]
Serial Port4 IRQ
[11]
Advanced
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
RS232
RS422
RS485
Options
Allows BIOS to select
Serial Port1 Base
Address.
BIOS SETUP UTILITY
← →
Select Screen
↑↓
Select Item
+-
Change Option
F1
General Help
F10 Save and Exit
ESC Exit
Configure ITE8783 Super IO Chipset
Serial Port1 Address
[3F8]
Serial Port1 IRQ
[3]
Serial Port1 Frequency Mode [RS232]
Serial Port1 Frequency Select [115200 bps]
Serial Port2 Address
[2F8]
Serial Port2 IRQ
[4]
Serial Port2 Frequency Mode
[RS232]
Serial Port2 Frequency Select [
Serial Port3 Address
Serial Port3 IRQ
Serial Port4 Address
Serial Port4 IRQ
Advanced
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
115200 bps
921600 bps
Options
