NEXCOM OPPC 1520T User Manual
Page 63
Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
48
Chapter 3: System Setup
OPPC 1520T/1720T User Manual
5. Connect one end of the provided cable to the connector on the mod-
ule.
Connector on
the module
Cable
6. Install the module to the SATA port via the connector at the solder side
of the module and then secure the module using the mounting screw
you removed in step 2.
SATA DOM
Mounting
screw
