Chapter 3: System Setup
OPPC 1520T/1720T User Manual
7. Insert the antenna jack end of the cable through the antenna hole.
Antenna jack
end of the cable
8. Insert the ring onto the antenna jack end of the cable.
Ring
Antenna jack
Antenna jack
Ring
