Chapter 4: BIOS Setup
OPPC 1520T/1720T User Manual
Super IO Configuration
This section is used to configure the I/O functions supported by the on-
board Super I/O chip.
Allows BIOS to select
Serial Port1 Base
Address.
BIOS SETUP UTILITY
← →
Select Screen
↑↓
Select Item
+-
Change Option
F1
General Help
F10 Save and Exit
ESC Exit
Advanced
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
Configure ITE8783 Super IO Chipset
Serial Port1 Address
[3F8]
Serial Port1 IRQ
[4]
Serial Port1 Frequency Mode [RS232]
Serial Port2 Address
[2F8]
Serial Port2 IRQ
[3]
Serial Port2 Frequency Mode [RS232]
Serial Port3 Address
[3E8]
Serial Port3 IRQ
[11]
Serial Port4 Address
[2E8]
Serial Port4 IRQ
[10]
Serial Port1 Address to Serial Port4 Address
3F8, 3E8, 2E8 Allows you to manually select an I/O address for the on
board serial port.
Disabled
Disables the onboard serial port.
Serial Port1 IRQ to Serial Port4 IRQ
These fields are used to select an IRQ for the onboard serial port 3, 4, 10
or 11.
Serial Port1 Frequency Mode
This field is used to select the frequency mode of serial port 1. The op-
tions are RS232, RS422 and RS485.
Allows BIOS to select
Serial Port1 Base
Address.
BIOS SETUP UTILITY
← →
Select Screen
↑↓
Select Item
+-
Change Option
F1
General Help
F10 Save and Exit
ESC Exit
Configure ITE8783 Super IO Chipset
Serial Port1 Address
[3F8]
Serial Port1 IRQ
[3]
Serial Port1 Frequency Mode [RS232]
Serial Port2 Address
[2F8]
Serial Port2 IRQ
[4]
Serial Port2 Frequency Mode
[RS232]
Serial Port3 Address
[3E8]
Serial Port3 IRQ
[10]
Serial Port4 Address
[2E8]
Serial Port4 IRQ
[11]
Advanced
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
RS232
RS422
RS485
Options
