Installing a mini pcie module – NEXCOM OPPC 1520T User Manual
Page 65
Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
50
Chapter 3: System Setup
OPPC 1520T/1720T User Manual
Installing a Mini PCIe Module
1. The Mini PCIe module package includes the following items.
Mini PCIe Module
Antennas
RF Cables
Mini PCIe slot
2. Insert the Mini PCIe module into the Mini PCIe slot at a 45 degrees
angle until the gold-plated connector on the edge of the module com-
pletely disappears inside the slot.
Mini PCIe
module
