background image

Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.

18

Chapter 2: Jumpers and Connectors

OPPC 1520T/1720T User Manual

Touch 4/5/8 Wire Select
Connector type: 1x3 3-pin header, 2.54 mm pitch
Connector location: JP8

1

3

Pin

Definition

1-2 On

5 wire

2-3 On

4/8 wire

1-2 On: default

LCD Panel Power Select
Connector type: 1x3 3-pin header, 2.54 mm pitch
Connector location: JP6

1

3

Pin

Definition

1-2 On: OPPC 1520T

3.3V

2-3 On: OPPC 1720T

5V

Pin

Definition

1

VCC3

2

Power for VDD

3

VCC5
