Chapter 4: BIOS Setup
OPPC 1520T/1720T User Manual
If you selected RS485 in the “Serial Port1 Frequency Mode”, the “Serial
Port1 Frequency Select” field will appear prompting you to select the fre-
quency setting. The options are 115200 bps and 921600 bps.
Allows BIOS to select
Serial Port1 Base
Address.
BIOS SETUP UTILITY
← →
Select Screen
↑↓
Select Item
+-
Change Option
F1
General Help
F10 Save and Exit
ESC Exit
Configure ITE8783 Super IO Chipset
Serial Port1 Address
[3F8]
Serial Port1 IRQ
[3]
Serial Port1 Frequency Mode [RS232]
Serial Port1 Frequency Select [115200 bps]
Serial Port2 Address
[2F8]
Serial Port2 IRQ
[4]
Serial Port2 Frequency Mode
[RS232]
Serial Port2 Frequency Select [
Serial Port3 Address
Serial Port3 IRQ
Serial Port4 Address
Serial Port4 IRQ
Advanced
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
115200 bps
921600 bps
Options
