Chapter 3: System Setup
OPPC 1520T/1720T User Manual
3. Mount the brackets to their corresponding mounting holes located on
the sides of the Panel PC.
Brackets and their corresponding
mounting screws
Mounting
holes
Bracket
4. The photo below shows the 4 brackets mounted in place.
Bracket
Bracket
Bracket
Bracket
