Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.

60

Chapter 3: System Setup

OPPC 1520T/1720T User Manual

3. Attach the front bezel onto the Panel PC.

Front bezel

Rear view

4. Viewing from the rear side of the bezel, the red dots denote the loca-

tions of the mounting screws.
