Chapter 2: Jumpers and Connectors
OPPC 1520T/1720T User Manual
Panel Resolution Select
Connector type: 8-pin On/Off Switch
Connector location: SWITCH1
O
N
1
2
3
4
5
6
7
8
Model
Resolution SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8
OPPC1520T 1024x768
OFF
OFF
ON
OFF
ON
ON
OFF
OFF
OPPC1720T 1280x1024
OFF
OFF
OFF
OFF
ON
ON
ON
OFF
