NEXCOM OPPC 1520T User Manual
Page 44
Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
29
Chapter 2: Jumpers and Connectors
OPPC 1520T/1720T User Manual
Reset Button
Connector type: 1x2 2-pin header, 2.0 mm pitch
Connector location: J8
1
2
Pin
Definition
1
RESET
2
GND
SATA DOM Power Connector
Connector type: 1x2 2-pin header, JST 2.0 mm pitch
Connector location: J1
1
2
Pin
Definition
1
5V
2
GND
