SDRAM Memory (U57)
SDRAM Memory
(U57) The SDRAM device (U57) is a Micron MT48LC4M32B2 with PC100
functionality and self refresh mode. The SDRAM is fully synchronous
with all signals registered on the positive edge of the system clock.
The SDRAM device pins are connected to the Stratix II device (see
Table 2–5 ). An SDRAM controller peripheral is included with the Nios II
development kit, allowing a Nios II processor to view the SDRAM device
as a large, linearly-addressable memory.
Table 2–5. SDRAM (U57) Pin Table (Part 1 of 2)
Pin Name Pin Number Connects to Stratix II Pin
A0 25 AD4
A1 26 AD3
A2 27 AD5
A3 60 W9
A4 61 W10
A5 62 AB10
A6 63 AF5
A7 64 AE5
A8 65 AC6
A9 66 AF6
A10 24 AA10
A11 21 Y9
BA0 22 AE23
BA1 23 AD23
DQ0 2 W15
DQ1 4 V14
DQ2 5 AA16
DQ3 7 AD16
DQ4 8 AF17
DQ5 10 AD17
DQ6 11 AF18
DQ7 13 AA17
DQ8 74 V16
DQ9 76 AB17
DQ10 77 AF19
DQ11 79 AD18
DQ12 80 AD19
