SX-AX15 (20) User Manual
Page 8
II. Initial Set-Up (continued)
Setting the IP address using the SCU
To access the Axess with the SCU from the default IP Address, the PC must be on the same
local network (IP address of 192.168.0.nnn).
Click File/Discover to automatically discover any Axess units on the same local network as the
computer. Discovered units will be listed in the Select list box.
Next select the unit to configure by clicking once on its name in the list box. Enter the
appropriate username and password and click the Download button. A Download popup will
appear; click the Download button to download the current configuration parameters of the
Axess.
Click the IP Address tab under the Setup section. Select the desired mode, Static or DHCP. If
using a Static IP address, specify the desired IP Address, Subnet, and Gateway.
Now click Connect (to the left of Control and Setup) to return to the Connect Panel and press
Upload to upload the new configuration.
If changes were made which require a reboot to take effect, the Reboot button is now available
and the unit’s name in the list box will be highlighted in red. Press the Reboot button to reboot
the Axess. The Axess will restart with the new settings.
Unix, Linux, MAC and others
Consult your systems administrator for information on how to set an IP Address. The unit should
be pinged after the IP Address has been set to confirm proper operation.
