SX-AX15 (20) User Manual
Page 33
XIV. Specifications
Parameter Specification
Load Rating 15/20 Amps at 120 Volts (SX-AX15 / SX-AX20)
Power Requirement (no load) 4 Watts
Surge Let-through Voltage (6000 Volt Surge) 0 Volts
UL 1449 Adjunct Classification Test Results 1000 Surges, 6000 Volts, 3000 Amps, B3 pulse;
measured suppressed voltage, 170 Volts; no failures
Maximum Applied Surge Voltage 6000 Volts *
Maximum Applied Surge Current Unlimited (due to current limiting) *
Maximum Applied Surge Energy Unlimited (due to current limiting) *
Endurance (C62.41-1991 category B3 pulses) 1 KV > 500,000; 3 KV > 10,000; 6 KV > 1000
EMI/RFI Filter Normal
mode (50Ω load)
40 dB@100 KHz, 50dB@300 KHz, 50 dB@3 MHz, 50
dB@30 MHz
Common Mode (50Ω load)
18dB@300 KHz, 30 dB@1 MHz, 50 dB@5 MHz, 50
dB@20 MHz
Under-Voltage Auto Shutdown Adjustable from 90V to 105V
Over-Voltage Auto Shutdown Adjustable from 135V to 150V
Over-Current Auto Shutdown Adjustable from 0A to 20A
Measurement Accuracy Voltage ± 1% from 40 – 180 V
RMS
Current ± 0.85A from 0 – 20 A
RMS
(Resistive)
Power ± 10% from 200 – 2400 W
RMS
(Resistive)
Energy ± 10% kWh
Network Port 10/100 Base T Ethernet connection on Female RJ-45
with Link and Activity LEDs
Modem Port V.92 and below on Female RJ-11 (for models with
internal modem option)
Serial Port RS-232 on Female 9-pin D-subminiature, DCE
Dimensions 19” W x 12.25” D x 1.75” H (Single Rack Space)
Weight 13 lb.
Temperature Range: 5C to 35C
Humidity Range 0% to 95% R.H. Non-condensing
Agency Listings TBD
* 1.2 x 50 microsecond industry standard combination wave surge as per IEEE C62.41
*CAUTION: Do not install this device if there is not at least 10 meters (30 feet) or more between the
electrical outlet and the electrical service panel.
