51
STEP 4: Check the module’s communication status.
VERIFY: The module’s green ACTIVE LED is on. This indicates that the
module is communicating properly with the rack.
CORRECTIVE ACTION:
• Set the rack into run mode.
• Reinstall the module in the rack.
STEP 5: Check the module’s health status.
VERIFY: The module is reported as healthy in the Modsoft I/O map Screen.
Check to make sure that the module description, slot location, and
register assignments are correct. Also, verify that the module is
recognized and reported as healthy. If an asterisk is present before
the module’s name, then the module is not recognized by the rack.
CORRECTIVE ACTION:
• Reinstall the module in the rack.
• Reselect the module in the I/O Map using the key. If the module
is not listed, install the Modsoft Runtime files included with your module.
STEP 6: Check the module’s register operation.
VERIFY: The 4X configuration word and the 3X+8 Status word are setup
properly. As a quick check, disable all ladder programming and set
the 4X register to 0000 Hex and verify that the 3X+8 Status register
cycles through the values 0000, 0001, 0010, and 0011 Hex.
CORRECTIVE ACTION:
• Check steps 1 through 6 above and then call Spectrum Controls Customer
Satisfaction at (425) 746-9481.
Installation Instructions
32-Channel Analog Input Module
Quantum 140 ACI 052 00sc
