Figure 2.3
❑ Alarm Enable: The second zoom screen, shown in figure 2.2, allows
the user to enable or disable alarms. Alarms are disabled by default.
If enabled, the limits defined by the user are used to monitor input
signals for alarm conditions and any alarm events will be captured
along with a time stamp for that event. Otherwise, no alarms will be
captured.
When an alarm occurs, the appropriate channel error flag for the
appropriate group is set in the status word (4x bits 1 through 8). The
user may then read each alarm in that group (up to 4 channels) by
setting the mode select bits to the Read Time Stamp Output mode (see
Chapter 4.1). If no alarm exists, all data will be 0.
When in the Read Time Stamp Output mode, the group select meaning
is different than it is in Read data and Read Channel Status modes.
Only two channels of information is available when reading time
stamps. The time stamp read channel select settings are as follows
(see Section 4.1 for more detail):
11
Installation Instructions
32-Channel Analog Input Module
Quantum Series 140 ACI 052 00sc
Hex Dec Bin Goto Quit
F1 F2 F3 F I/O Map Module Editor F7 Lev 8 F8 OFF F9
140 ACI 050 00SC 32 CHANNEL ANALOG V/I WITH TIMESTAMP Screen 3/3
Head-Slot: 0 Drop: 1 Slot: 5 Spectrum Controls, Inc
P.O. Box 5533
Bellevue, WA 98006
(425) 746-9481
Alarm Limits (Channels 17 through 32)
Assume same data format and range as used for the relevent channel pair.
Channels 17 and 18 LOW = -10000 DEC HIGH = 10000 DEC
Channels 19 and 20 LOW = -10000 DEC HIGH = 10000 DEC
Channels 21 and 22 LOW = -10000 DEC HIGH = 10000 DEC
Channels 23 and 24 LOW = -10000 DEC HIGH = 10000 DEC
Channels 25 and 26 LOW = -10000 DEC HIGH = 10000 DEC
Channels 27 and 28 LOW = -10000 DEC HIGH = 10000 DEC
Channels 29 and 30 LOW = -10000 DEC HIGH = 10000 DEC
Channels 31 and 32 LOW = -10000 DEC HIGH = 10000 DEC
End of 140 ACI 052 00SC Zoom
