74

SLC 500

Universal Analog Input Module

Physical

Specifications

LED Indicators

9 green status indicators, one for each of 8

channels and one for module status

Module ID Code

3500

Recommended Cable:

for thermocouple inputs...

Shielded twisted pair thermocouple extension wiren

for mV, V or mA inputs

Belden 8761 or equivalent

for RTD inputs

shielded Belden #9501, #9533, #83503o

Maximum Wire Size

One 16 AWG wire or two 22 AWG wires per terminal

n

Refer to the thermocouple manufacturer for the correct extension wire.

o

Refer to the RTD manufacturer and Chapter 1 of this user’s manual.

EnvironmentalSpecifications

Operating Temperature

0°C to 60°C (32°F to 140°F)

Storage Temperature

-40°C to 85°C (-40°F to 185°F)

Relative Humidity

5% to 95% (without condensation)

Certification

UL & CUL approved

Hazardous Environment

Class1 Division 2 Hazardous Environment

Classification

Groups A, B, C, D

EMC

CE compliant

Input Specifications

Thermocouple Type J

-210°C to 760°C

(-346°F to 1400°F)

Thermocouple Type K -270°C to 1370°C (-454°F to 2498°F)

Thermocouple Type T -270°C to 400°C

(-454°F to 752°F)

Thermocouple Type E -270°C to 1000°C (-454°F to 1832°F)

Type of Input (Selectable) Thermocouple Type R

0°C to 1768°C

(32°F to 3214°F)

Thermocouple Type S 0°C to 1768°C

(32°F to 3214°F)

Thermocouple Type B 300°C to 1820°C

(572°F to 3308°F)

Thermocouple Type N

0°C to 1300°C

(32°F to 2372°F)

Thermocouple Type C

0°C to 2315°C

(32°F to 4199°F)

Millivolt (-50 mVdc to +50 mVdc)

Millivolt (-100 mVdc to +100 mVdc)

Millivolt (±500mV, ±2V, 0-5V, 1-5V, 0-10V, ±10V)

Current (4 to 20mA)

Current ( 0 to 20mA)

RTD Pt 385

-200°C to 850°C

-328°F to 1562°F

(100

, 500

, 1000

)

RTD Pt 385

-200°C to 750°C

-328°F to 1382°F

(200

)

RTD Pt 3916

-200°C to 630°C

-328°F to 1166°F

(100

, 200

, 500

, 1000

)

RTD 10

Cu 426

-100°C to 260°C

-148°F to 500°F

RTD 120

Ni 618

-100°C to 260°C

-148°F to 500°F

RTD 120

Ni 672

-80°C to 260°C

-112°F to 500°F

Resistance (0 to 3000

Ω)
