ii SLC 500 ™ Universal Analog Input Modules
Table A. Related Allen-Bradley documents
Allen-Bradley Doc. No. Title
1747-2.30 SLC 500 System Overview
SGI-1.1 Application Considerations for Solid State Controls
1770-4.1 Allen-Bradley Programmable Controller Grounding and
Wiring Guidelines
1747-6.2 Installation & Operation Manual for Modular Hardware
Style Programmable Controllers
1747-NI001 Installation & Operation Manual for Fixed Hardware Style
Programmable Controllers
1747-6.4 Allen-Bradley Advanced Programming Software (APS)
User Manual
1747-6.11 Allen-Bradley Advanced Programming Software (APS)
Reference Manual
1747-6.3 Getting Started Guide for Advanced Programming
Software (APS)
ABT-1747-TSG001 SLC 500 Software Programmers’s Quick Reference Guide
1747-NP002 Allen-Bradley HHT (Hand-Held Terminal) User Manual
1747-NM009 Getting Started Guide for HHT (Hand-Held Terminal)
SD499 Allen-Bradley Publication Index
AG-7.1 Allen-Bradley Industrial Automation Glossary
To obtain a copy of any of the Allen-Bradley documents listed, contact
your local Allen-Bradley office or distributor.
Terms &
Abbreviations You
Should Know You should understand the following terms and abbreviations before using
this guide.
A/D - Refers to analog-to-digital conversion. The conversion produces a
digital value whose magnitude is proportional to the instantaneous
magnitude of an analog input signal.
Attenuation – The reduction in magnitude of a signal as it passes through
a system. The opposite of gain.
Channel – Refers to one of eight, small-signal analog input interfaces to
the module’s terminal block. Each channel is configured for connection to
a thermocouple or DC millivolt (mV) input device, and has its own
configuration and status words.
Chassis – See rack.
