2 SLC 500 ™ Universal Analog Input Module
Table 1.2 RTD Temperature Ranges
Type °C Temperature Range °F Temperature Range
Platinum (385) 1 100 Ohm -200°C to +850°C -328°F to +1562°F
200 Ohm -200°C to +750°C -328°F to +1382°F
500 Ohm -200°C to +850°C -328°F to +1562°F
1000 Ohm -200°C to +850°C -328°F to +1562°F
Platinum (3916) 1 100 Ohm -200°C to +630°C -328°F to +1166°F
200 Ohm -200°C to +630°C -328°F to +1166°F
500 Ohm -200°C to +630°C -328°F to +1166°F
1000 Ohm -200°C to +630°C -328°F to +1166°F
Copper (426) 10 Ohm -100°C to +260°C -148°F to +500°F
Nickel (618) 120 Ohm -100°C to + 260°C -148°F to +500°F
Nickel (672) 120 Ohm -80°C to +260°C -112°F to + 500°F
1= The digits following the RTD type represent the temperature coefficient of resistance
(alpha, a), which is defined as the resistance change per Ohm per
° °
C. For instance,
Platinum 385 refers to a platinum RTD with a = 0.00385 Ohms/Ohm -
° °
C, or simply
0.00385/
° °
C.
Table 1.3 Millivolt Input Ranges
-50 to +50 mV
-100 to +100 mV
-500 to +500 mV
-2.0 to +2.0 V
0 to +5.0 V
1.0 to +5.0 V
0 to 10.0 V
-10.0 to +10.0 V
Table 1.4 Current Input Ranges
4 to 20 mA
0 to 20 mA
Table 1.5 Resistance Input Range
0 to 3000 Ohms
