P
ARTS
L
ISTS
& D
RAWINGS
6300
F
w w w . p a r r i n s t . c o m 95
A
PPENDIX
F
P
ARTS
L
ISTS
& D
RAWINGS
P
RINCIPAL
A
SSEMBLIES IN
C
ALORIMETER
Item Description
1136/1136CL O2 Combustion Vessel, 340 mL
1138/1138CL O2 Combustion Vessel, 250 mL
1795E Power Supply, 24V
1796E Power Supply, 5/12V
379VB2 Barbed Tee, 3/8T X 1/2T X 3/8T
412VB Union Fitting, drain
533VBAD Union Reducer, 3/8T – 1/4T
897E Capacitor, Ignition
909E Switch Power
911E Filter 10 amp, interference
A1050DD Rinse Container Assembly
A1250DD2 Controller Assembly
A1251DD Oxygen Solenoid Assembly
A1252DD Water Solenoid Assembly
A1416DD Wash Pump Assembly
A1254DDEB Pump Assembly Circulating 115V
A1254DDEE Pump Assembly Circulating 230V
A1255DD Propeller Assembly, stirrer
A1256DD Water Tank Assembly
A1257DD Water Regulator Assembly
A1260DD Water Level Assembly
A1264DD Air Can Assembly 6300
A1265DD Bucket and Stirrer Tube Assembly
A1275DDEB Cartridge, Heater Assembly, 120V
A1275DDEE Cartridge, Heater Assembly, 230V
A1274DD Wash Pump Divert Valve Assembly
139E23 Fuse Fast/ Act 15 Amp 250V
1641E Pump Fuse (F1), Fast-Act, 1 Amp, 250V
1641E2 Heater Fuse (F2), Fast-Act, 2.5 Amps, 250V
997E5 Bomb Rinse (F5), Slo-Blo, 5 Amps, 250V
WARNING:
For continued protection against possible hazard, replace fuses with
same type and rating of fuse.
