Parr Instrument 6300 - Manual (Page 100)

F
P
ARTS
L
ISTS
& D
RAWINGS
P a r r I n s t r u m e n t C o m p a n y 100
6300 S
TIRRER
M
OTOR AND
D
RIVE
A1255DD B
UCKET
S
TIRRER
A
SSEMBLY
Item Description
682DD Snap Ring, Internal .50
683DD Wave Spring, .50 OD
684DD Ball Bearing, .50 OD
690DD V-Seal, Nitrile
715HC O-ring NBR 1-1/4 ID
954DD Propeller
1029DD Baffle Assembly
1242DD2 Pulley, Timing (6300)
SA114ORD04 4-40 X 1/4 RHMS 18-8 SS
SN1140HLHJ Nut, 4-40 Hex Lock
A1266DD C
OVER
A
SSEMBLY
Item Description
Contact Pin Assembly
986DD Pin Contact
987DD Block Contact Pin
988DD Spring Compression
989DD Snap Ring External .219”
1021DD Bushing 0.125 ID
SN1332HX 6-32 Hex Nut 18-8 SS
A1400DD Plunger/Knob Assembly
1218DD Cover, Air
1229DD3 Plate
1237DD2 Friction Hinge
1396DD Latch Block
1324DD2 Post, Latch Locking
A1230DD2 Cover/Tubing Assembly
HA0012TB031 Tubing, PTFE
