Figure F-6
A1250DD2 Control Schematic
P8 USB PORT
J8
J10
P6
J1
A1821E
PIN #1
USB PORT
J5
J1
BOARD TO DISPLAY CABLE
IO BOARD
A2163E LCD CABLE ASSY
J8
ASSEMBLY
A1823E TOUCH
PIN #1
J9
A2165E
BOARD
J9
J6
DETAIL "A"
LCD TRANSISTION
TRANSITION
1472DD
ON ENCASEMENT)
J1
LCD ENCASEMENT
A2164E BACKLIGHT CONTROL CABLE ASSY
J17
2147E
J19
J6
J2
J4
A2140E
(SEE SHEET 2 FOR INSTALLATION
CABLE SPEAKER
LCD DISPLAY
SCREEN CABLE ASSY
J10
BACK PANEL
A2141E
CONTACTS ARE EXPOSED IN THIS VIEW
J100
A2167E USB PERIPHERAL CABLE ASSY
CONNECTS IN LOWER PORT OF J4 ON CPU
CONNECTS IN UPPER PORT OF J4 OF CPU
A1822E POWER CABLE ASSY A2166E IO TO CPU USB CABLE ASSY (RED WIRE ON CABLE CONNECTS TO PIN #1)
A2154E
CPU BOARD
A2165E REF
A
A
