Martin Christ Alpha 1-2 LDplus - Manual (Page 65)

Freeze-dryer Alpha 1-2 LDplus
10 Technical data
Version 11/2006, Rev. 2.0 of 02/12/2014 • sb
65
Translation of the original operating manual
Physical data
(without vacuum pump and accessories)
Dimensions
- height:
- width:
- depth:
345 mm
315 mm
460 mm
(incl. vacuum flange connection)
Weight: approx. 28 kg
Noise level
according to DIN 45635: 49 dB(A)
EMC according to EN 55011: Class B
Heat emission: 0.51 kW min.
0.91 kW max.
Equipment connections
Vacuum connection: Small flange connection DN25KF
(ISO 28403, DIN 2861)
Aeration and media drain valve: Hose nozzle DN10 (outside diameter 12 mm)
Mains input: IEC C13 connector
Vacuum sensor: SUB D-9
VSP 62/63
Option: Data interface (LAN): RJ 45
Pos: 201 /01 0 Univ ersal mod ule/L eerz eile @ 0\m od_ 120 211 624 450 0_0. docx @ 11 4 @ @ 1
Pos: 202 /01 0 Univ ersal mod ule/L eerz eile @ 0\m od_ 120 211 624 450 0_0. docx @ 11 4 @ @ 1
Pos: 203 /20 0 Ch rist/3 60 G T-BA L abo r-Pilot (STANDARDMODU LE)/1 00 Tech nische D ate n/10 0-0 010 Um geb ungs bedin gun gen -- --- --- -- --- -- --- --- -- --- -- --- -- --- --- -- --- -- @ 25 \mo d_1 404 9841 557 72_ 68.d ocx @ 184 573 @ 2 @ 1 10.1 Umgeb ungs bedi ngu nge n
10.1 Ambient conditions
Pos: 204 /20 0 Ch rist/3 60 G T-BA L abo r-Pilot (STANDARDMODU LE)/1 00 Tech nische D ate n/10 0-0 010 Um geb ungs bedin gun gen Tex t @ 2 5\m od_ 140 498 415 4817 _68 .docx @ 1 845 59 @ @ 1 10.1 Umgeb ungs bedi ngu nge n
• The figures are valid for an ambient temperature of +20°C.
• Allowable ambient temperature +10 °C to +25 °C.
• Max. humidity 85% (non-condensing) at +25°C.
Pos: 205 /01 0 Univ ersal mod ule/L eerz eile @ 0\m od_ 120 211 624 450 0_0. docx @ 11 4 @ @ 1
Pos: 206 /01 0 Univ ersal mod ule/L eerz eile @ 0\m od_ 120 211 624 450 0_0. docx @ 11 4 @ @ 1
Pos: 207 /20 0 Ch rist/3 60 G T-BA L abo r-Pilot (STANDARDMODU LE)/1 00 Tech nische D ate n/10 0-0 020 T echnisc he D okum ent ation @ 25 \mo d_1 404 984 156 884_ 68. docx @ 18 458 7 @ 2 @ 1
10.2 Technical documentation
The technical documentation of this freeze-dryer (e.g. circuit diagram,
cooling system ) and the safety data sheets of the manufacturers of
refrigerant and heat transfer medium is not attached to this operating
manual.
You can order these documents from our service department.
