2.1 Layout of the freeze-dryer
Pos: 19 / 200 Christ /36 1 GT -BA La bor -Pilot (PROJEKTE )/Alpha 1- 2 LDpl us/0 20 Auf bau und Wirkun gsweis e/02 0-0 010 -00 10 Fu nktions - u nd Be dienel eme nte Alp ha 1-2 LDplus @ 3 1\mo d_1 408 084 045 900 _68. docx @ 20 929 8 @ 3 @ 1
2.1.1 Functional and operating elements
1
Ice condenser chamber
with an internal ice
condenser
2 Aeration and media drain
valve
Fig. 1:
Left side of the freeze-dryer
3
Pipe connection of the
vacuum pump (behind
the cover plate)
4 Ice condenser
Fig. 2:
Ice condenser chamber
