Freeze-dryer Alpha 1-2 LDplus
4 Storage and transport
Version 11/2006, Rev. 2.0 of 02/12/2014 • sb
31
Translation of the original operating manual
Pos: 87 / 200 Christ /36 1 GT -BA La bor -Pilot (PROJEKTE )/Alpha 1- 2 LDpl us/0 40 L age run g un d T ran spo rt/0 40- 0040 Ver pack ung Alp ha 1 -2 LDplus @ 31 \mo d_1 408 084 061 156 _68. docx @ 20 935 5 @ 2 @ 1
4.4 Packaging
The freeze-dryer is packaged in a cardboard box or in a wooden crate,
depending on the scope of supply.
• After opening the packaging, take out the box containing the
accessories.
• Remove the packaging material.
• Lift the freeze-dryer upwards and out of the crate/cardboard box. When
lifting the unit, always reach under the freeze-dryer from the side.
CAUTION
The freeze-dryer Alpha 1-2 LDplus weighs approx. 28 kg!
• Retain the packaging for any possible future transport of the freeze-
dryer.
Pos: 88 / 010 Unive rsalm odul e/Le erzeil e @ 0\mo d_1 202 116 244 500 _0.d ocx @ 114 @ @ 1
Pos: 89 / 200 Christ /36 1 GT -BA La bor -Pilot (PROJEKTE )/Alpha 1- 2 LDpl us/0 40 L age run g un d T ran spo rt/0 40- 0050 Tra nspo rtsich eru ng Alph a 1 -2 LD plus @ 31\ mod _14 080 840 614 20_6 8.d ocx @ 209 369 @ 2 @ 1
4.5 Transport safety device
Prior to start-up, the vacuum sensor must be installed (see chapter 5.4 -
"Vacuum sensor").
NOTE
Prior to any transport, the vacuum sensor must be deinstalled.
