Freeze-dryer Alpha 1-2 LDplus
10 Technical data
64
Version 11/2006, Rev. 2.0 of 02/12/2014 • sb
Translation of the original operating manual
Pos: 200 /20 0 Ch rist/3 61 G T-BA L abo r-Pilot (PROJEKTE)/Alph a 1 -2 LD plus/ 100 Tec hnisch e Dat en/1 00 Tec hnisch e Dat en Alp ha 1 -2 LDplus == === == == === == == === == == @ 31\ mo d_1 408 0840 934 61_ 68.d ocx @ 209 483 @ 1 @ 1
10 Technical data
Manufacturer: Martin Christ
Gefriertrocknungsanlagen GmbH
An der Unteren Söse 50
37520 Osterode (Germany)
Type: Alpha 1-2 LDplus
Part number: 101521
Performance data
Ice condenser
- capacity:
- performance:
- temperature:
- chamber volume:
2.5 kg max.
2 kg / 24 h max.
approx. –55°C
approx. 3.5 l
Shelf or product temperature
during freezing in the ice condenser chamber approx. –25°C
Max. shelf surface ( process B):
drying outside the ice condenser chamber
drying in injection vials with sealing under vacuum or
nitrogen atmosphere outside the ice condenser
chamber
drying in round bottom flasks
3 shelves, Ø 200 mm, A
total
=0.092m 2
distance up to 80 mm, with accessory, part no. 120893
2 shelves, 200 mm, A
total
=0.054 m 2
distance 25-70 mm, with accessory, part no. 121015
8 pieces, with accessory, part no. 121450
Connection requirements
(without vacuum pump and accessories)
Electrical connection: 1 x 230 V / 50-60 Hz
Protection class: I
IP protection category according to DIN 60529: 11
Nominal power: 0.66 kVA
Nominal current: 3.0 A
Mains fuse: 6.3 A T
Pressure control valve connection: 230 V, 50/60 Hz, 20 VA / 0.5 A max.
Vacuum pump connection: 230 V, 50/60 Hz, 2.5 A max.
Filling quantity
Refrigerant: see name plate
