IPTV Analysis
62 AXS-200/630
Reading Results
WAN Status
The WAN Status tab allows you to view the status of the connection
between the wide area network and the ISP.
The available test results are the
following:
³
WAN Access specifies the type of
wide area network access, either
Bridged or Routed mode.
³
Status displays either Connected
or Disconnected for the particular
line connection under test.
³
Encapsulat is the encapsulation method used by the network and
consists of four types.
³
PPPoE is point-to-point protocol over Ethernet.
³
PPPoA is point-to-point protocol over ATM.
³
Bridged Ether DHCP is also known as multi-protocol
encapsulation over ATM (MPoA).
³
IPoA stands for classical internet protocol over ATM.
