VDSL2, ADSL2+, and IP Triple-Play Test Set 7
2 Getting Started
Navigating through the AXS-200/630
The Navigation menu allows you to access all the test options available
with the AXS-200/630.
³
To navigate through the items, use the arrow keys.
³
To confirm a choice or enter a menu, press .
³
To cancel an action or return to the previous item or window,
press
.
³
To return to the home window, press .
Line Tests Menu
The Line Tests pane lists all the test capabilities of the unit.
To access the DSL/Ethernet-based
tests:
1. From the Home page, use the up
or down arrow key to highlight
Line Tests, then press
.
2. From the Line Tests pane,
highlight the desired menu item
and press
; or press the
corresponding menu item number.
³
When selected, each of the five tests start, using the connection setup
from the current profile.
³
Connection Setup allows you to setup a series of connection
parameters for Auto Test and CPE testing, IPTV, data, and VoIP analyses
beginning with the Select Profile tab.
³
Configure Tests allows you to configure a series of test parameters to
verify applications, beginning with Auto Test.
³
Read Saved Result allows you to view the Read Results page.
