Connection Setup for xDSL/IP Triple-Play Verification Tests
VDSL2, ADSL2+ and IP Triple-Play Test Set 17
Setup Line Connection
WAN IP
The WAN IP tab allows you to configure the wide area network parameters
required to connect to the ISP for a Selected Profile composed of the
current LineMode and AccessMode selections.
When the AccessMode selection is set
to Routed BrgdEthernet DHCP, the
available parameters are the
following:
³
Vendor ID is the name of the unit,
maximum 80 characters.
³
Local MAC Address is the internal
MAC address of the unit: either
AXS200 or User Defined.
³
MAC Address is a specific MAC address, maximum 17 characters, if
you select User Defined for the previous parameter.
