Connection Setup for xDSL/IP Triple-Play Verification Tests
VDSL2, ADSL2+ and IP Triple-Play Test Set 19
Setup Line Connection
When the AccessMode selection is set
to Routed PPPoE or Routed PPPoA,
the available parameters are the
following:
³
Obtain IP is either Dynamic
where the access concentrator or
broadband remote access server
assigns a temporary IP address to
the unit, or Static where you enter
the IP address of the unit.
³
Static IP is the address for the unit that is actively connected to your
network or the internet at the time of login. This entry is unavailable if
Obtain IP is set to Dynamic.
³
Login Name is your user ID.
³
Password is your user password.
When the AccessMode selection is set
to Routed IPoA, the available
parameters are the following:
³
IP Address is the address for the
unit that is actively connected to
your network or the internet at the
time of login.
³
Gateway is the IP address of the
default gateway.
³
Subnet Mask is the network address used to identify if the IP address is
within the same wide area network.
³
DNS1 is the address of the primary domain name server to be used by
the unit. If DNS is unavailable, enter 0.0.0.0.
³
DNS2 is the address of the secondary domain name server to be used
by the unit. If DNS is unavailable, enter 0.0.0.0.
