Windows XP Information
GPS Module D - 55
D
Configuring the COM Port for the GPS Module
You need to make sure that the COM port for the GPS module is set to COM 3 at a
4800 baud rate. To do this follow the instructions below:
1. Click Start (menu), point to Settings and click Control Panel (or click Control Panel).
2. Double-click System (icon); System (icon) is in Performance and Maintenance (category).
3. Click the Hardware (tab) > Device Manager (button).
4. Click “+” next to Ports (COM & LPT) if its sub-items are not shown.
5. Double-click Communications Port (COM3).
6. Click Port Settings (tab) and make sure that the Bits per second rate is set to 4800 baud.
7. Click OK and close the Device Manager.
Figure D - 33
COM3 Port Settings
for the GPS Module
