Modules

RFID Reader Module 6 - 25

6

Configuring the COM Port for the RFID Reader

You need to make sure that the COM port for the RFID reader is set to COM 1 at a
9600 baud rate. To do this follow the instructions below:

1.

Click Start (menu), point to Settings and click Control Panel (or click Control Panel).

2.

Double-click Device Manager (icon); Device Manager (icon) is in Hardware and
Sound (category).

3.

Click “+” next to Ports (COM & LPT) if its sub-items are not shown.

4.

Double-click Communications Port (COM1).

5.

Click Port Settings (tab) and make sure that the Bits per second rate is set to
9600 baud.

6.

Click OK and close the Device Manager.

Figure 6 - 18

COM1 Port Settings
for the RFID Reader
