-47-
INSTALL COMPLETED UNIT INTO CASE
r Place the strain relief onto the line cord as shown in Figure N.
r Squeeze the two sections together with pliers as shown in Figure O. Then, insert the strain relief into the
hole.
r Lay the trainer inside of the case as shown in Figure P.
r Align the holes in the bottom case with those in the trainer and secure it into place with four #6 x 1/2” AB
screws and four #6 washer as shown in Figure Q.
Figure P Figure Q
Figure N Figure O
#6 x 1/2” AB Screw
#6 Washer
Back Panel Back Panel
