Elenco Deluxe Digital / Analog Trainer with Tools Kit Version User Manual
Page 39
-38-
USERS DESCRIPTION OF FRONT PANEL
1. Output Terminals - For all functions as stated. 4 pins per block.
2. Two Logic Switches - These are no bounce logic switches. Give one signal state change per movement
of switch.
3. Input Terminals for Logic Indicator LEDs - “A” input corresponds with “A” lamp, etc.
4. Logic Indictators - Eight LEDs.
5. Eight Data Switches - Lets output of 5V or 0V depending on position.
6. Output Terminal - For all functions as stated. 4 pins per block.
7. Breadboard - One breadboard containing 730 tie points.
1
2
3
4
5
6
7
