IP025-001 V3
IBL Lift Series Installation
07/05 Thor/Sales Info/Installation Materials/IBL Lift 4
Lift Placement and Location
Verify the projector’s lens offset from the center of the projector and center the lens
onto the center of the projection screen.
If your lens is offset from the center of the projector, the lift should have the same
opposing offset to center.
Ensure that the centerline of the lens remains aligned with the centerline of the screen.
If your projector does not have a zoom lens, the focal length distance and image size
from screen to lift is critical. See your specific projector manual for detail.
Verify where the front of the projector’s lens is in relationship to the lift, and
compensate accordingly.
INSTALLATION
Mounting hardware is not provided. Be sure to have all your mounting hardware and
tools readily accessible before installation. Consult your local building codes for proper
structural attachment.
Here are the tools you will need:
Safety glasses
Socket set with 7/16” socket wrench
Box wrenches
1/16” hex drive
Philips Head Screwdriver
Adjustable wrench
Magnetic torpedo level (two, if possible)
Ladders or manlift
Genie Lift, or heavy straps and pulleys (for DataLift and DataLite Models)
Knockout kit or hole saw
½” drill and/or ½” hammer drill
