5 Yellow
– O
/R
(5ma draw)
4 Blue - SET (5ma draw)
3 Green -
STO
P (5ma draw)
2 Red - DOWN
(5ma draw)
1 Black
– UP (5ma draw)
6 Wh
ite -
(Grou
nd
)
7 Purple
– LE
D
(20ma draw)
9 Brown +5V
9 Orange - Sa
fe
ty Switch O/R (5ma draw)
DOWN
UP STOP
O/
R
SET
SAF
ETY O
/R
LED
Digital R
emot
e
Interface Schematic
22 AWG for cable runs
up to 100 feet
20 AWG for cable runs
that are 100 to 500 feet
NOTE: O/R = OVERRIDE Do not connect or short an
y wires to Pin 8
or 9 except Safety Override Button
