Hand-held Remote Control Unit
Model # S10018
The Display Devices Hand-held Remote Control Unit is a versatile, multi-functional
programmable remote for lift operation.
The UP button moves the lift to the home position in AUTOMATIC mode, and raises the
unit intermittently on command in MANUAL mode.
The DOWN button lowers the lift to its SHOW position in AUTOMATIC mode, and
lowers the unit intermittently on command in MANUAL mode.
The SET and OVERRIDE buttons on the back of the unit are used in combination with
the three command buttons on the front to program the remote control to run the lift.
The EMERGENCY button is only to be accessed only in the unlikely case of the lower
limit switch being activated. This will be discussed later.
* It is recommended to keep the handheld 9-pin remote attached to the control box in
addition to any control system for easy maintenance override or in case of control
system failure.
Front Back
UP
DOWN
STOP
EMERGENCY – accessible only
with back cover removed
SET
These two bottoms are accessed with a small point
OVERRIDE
