HOW DO I…
Set the SHOW position
This is the intermediate level for “on screen” projection.
1. Program the remote to MANUAL MODE - Press and hold the OVERRIDE button
then press the UP button. Release UP then release OVERRIDE.
2. Lower the lift with the DOWN button to its desired projection position.
3. To program the remote to the SHOW position: press and hold the SET button then
press the UP button. Release UP then release SET.
4. To return the remote to the AUTOMATIC MODE, press and hold the OVERRIDE
button, followed by the STOP button. Release STOP, then OVERRIDE.
5. Return the lift to the HOME position by pressing the UP button once.
6. Test the operation of the lift to verify it has accepted your program.
7. Press the DOWN button once. The lift will travel to its programmed position. If the
lift does not travel to the position just programmed, repeat this process.
* Remember, the remote must be in AUTOMATIC MODE for the commands to operate
correctly.
Front Back
UP
DOWN
STOP
SET
These two bottoms are accessed with a small point
OVERRIDE
