Display Devices Lifts up up 35 lbs User Manual
Page 2
IP025-001 V3
IBL Lift Series Installation
07/05
Thor/Sales Info/Installation Materials/IBL Lift
2
Contents
Important Installation Notes
3
Lift
Placement
4
Installation
4
Control
Settings
5
Plenum Enclosure Assembly
6
Physical Installation – top mounting
7
Physical Installation – side mounting
9
Connecting
Power
11
Projector
Mounting
13
Cabling
the
Lift
13
Ceiling
Closure
15
Final
Adjustments
17
Specifications
17
Lift
Removal
18
Maintenance and Safety
18
Emergency
Operation
19
Remote Control Operation and Programming
20
Digital 9 pin Interface Schematics
29
Troubleshooting
Chart
30
Warranty
31
Installation
Feedback
Form
32
