IP025-001 V3
IBL Lift Series Installation
07/05 Thor/Sales Info/Installation Materials/IBL Lift 28
SETTING MAINTENANCE AND SHOW POSITIONS
Put the Lift into
Manual Mode
Press OVERRIDE & UP
If yes, press UP
and lift is ready for
operation
If no, press UP and
start again
Press DOWN to lower lift
to desired Maintenance
position (lift will stop
when button in released)
Set Maintenance position
Press SET & STOP
Return to AUTO mode
Press OVERRIDE & STOP
Press UP button, lift
should travel to home
To test: Press OVERRIDE
& STOP buttons, lift
should travel to position
just set and then stop
If no, press UP and
start again
If yes, press UP
and lift is ready for
operation
Press DOWN to lower lift
to desired Show position
(lift will stop when button
is released)
Set Show position
Press SET & UP
To test: Press DOWN
button, lift should travel
to position just set and
then stop
Return to AUTO mode
Press OVERRIDE & STOP
Press UP button, lift
should travel to home
