IBL Lift Series Installation
07/05
Thor/Sales Info/Installation Materials/IBL Lift
26
7.
Press both the OVERRIDE and SET buttons at the same time. This will reset the
electronic lower limit switch.
8.
Return the remote to AUTOMATIC MODE (OVERRIDE + STOP).
9.
Press the UP button, and allow the lift to travel up to its home position.
*Hold in the EMERGENCY OVERRIDE button (the LED will stop blinking). Keep the
EMERGENDY OVERRIDE button held, then press and hold the UP button. Keep both
buttons held until the lift has moved six inches. Allow the lift to travel all the way to the
home position.
Front Back
UP
DOWN
STOP
SET
These two bottoms are accessed with a small point
OVERRIDE
