IP025-001 V3
IBL Lift Series Installation
07/05 Thor/Sales Info/Installation Materials/IBL Lift 23
HOW DO I?
Set the SERVICE / MAINTENANCE position
This is lower than the SHOW setting, bringing the lift to a level making maintenance,
service, lamp and filter changes, and projector adjustments easier.
1. Program the remote to MANUAL MODE - Press and hold the OVERRIDE button
then press the UP button. Release UP, then release OVERRIDE.
2. Lower the lift with the DOWN button to its desired position for the easiest
access for maintenance and repair.
3. To program the remote to the SERVICE/MAINTENANCE position, press and hold
the SET button, followed by the STOP button. Release the STOP, then SET
buttons.
4. To return the remote to the AUTOMATIC MODE, press and hold the OVERRIDE
button, followed by the STOP button. Release the STOP, then OVERRIDE
buttons.
5. Return the lift to the HOME position by pressing the UP button once.
6. Test the operation of the lift to verify it has accepted your program, press and
hold the OVERRIDE button, followed by the DOWN button. The lift will travel
to its programmed position.
Remember, the remote must be in AUTOMATIC MODE for the programs and
operations to operate correctly.
Front Back
UP
DOWN
STOP
SET
These two bottoms are accessed with a small point
OVERRIDE
