DES-3226 NWay Standalone Fast Ethernet Switch User’s Guide
Configure Class of Service, Default Priority and Traffic Class
The DES-3226 allows you to customize class of service, port default priority, and traffic class settings
on the following menu.
Select Configure Class of Service, Default Priority and Traffic Class on the Configuration menu
and press Enter.
Figure 6-34. Configure Class of Service, Default Priority and Traffic Class menu
Class of Service Configuration
Select Configure Class of Service and press Enter to access the following screen:
Figure 6-35. Class of Service Configuration screen
This screen allows you to set the following features:
• Max. Packets – The Class of Service scheduling algorithm starts from the highest CoS for a given
port, sends the maximum number of packets, then moves on to the next lower CoS. The values that
64
