Page 160
DES-3226 NWay Standalone Fast Ethernet Switch User’s Guide
B
RJ-45 P
IN
S
PECIFICATION
When connecting the Switch to another switch, a bridge or a hub, a normal cable is necessary. Please
review these products for matching cable pin assignment.
The following diagram and table show the standard RJ-45 receptacle/connector and their pin
assignments for the switch-to-network adapter card connection, and the normal cable for the Switch-to-
switch/hub/bridge connection.
Figure B-1. The standard RJ-45 receptacle/connector
150
