DES-3226 NWay Standalone Fast Ethernet Switch User’s Guide

Note: Configuration files used in the earlier version of this switch (firmware version 1.0) are not

supported by the present version (firmware version 2.0). The Switch Information window displays
the firmware version.

Save Settings

The Switch’s current settings can be uploaded to a TFTP Server by the Switch’s management agent.

Figure 7-60. Save Settings To TFTP Server window

Enter the IP address of the TFTP Server in the Server IP Address field and the complete path and file
name of the firmware file for the Switch. Click Apply to enter the server’s IP address into the Switch’s
RAM (use Save Changes to enter the address into the Switch’s non-volatile RAM). Click Start to initiate
the file transfer.

Please note that if the user does not save configurations to NV-RAM, the configurations the user is
uploading to a TFTP server will not be saved correctly.

The information is described as follows:

Server IP Address – The IP address of the TFTP server.

File Name – The full file name (including path) of the new firmware file on the TFTP server.

Save History Log

The Switch’s management agent can upload its history log file to a TFTP server.

Please note that an empty history file on the TFTP server must exist on the server before the Switch can
upload its history file.

Figure 7-61. Save Switch History To TFTP Server window

Enter the IP address of the TFTP Server in the Server IP Address field and the complete path and file
name of the firmware file for the Switch. Click Apply to enter the server’s IP address into the Switch’s
RAM (use Save Changes to enter the address into the Switch’s non-volatile RAM). Click Start to initiate
the file transfer.

The information is described as follows:

143
