DES-3226 NWay Standalone Fast Ethernet Switch User’s Guide
E
B
RIEF
R
EVIEW OF
B
ITWISE
L
OGICAL
O
PERATIONS
AND
The logical AND operation compares 2 bits and if they are both “ 1”, then the result is “1”,
otherwise, the result is “0”.
0 1
0 0 0
1 0 1
OR
The logical OR operation compares 2 bits and if either or both bits are “1”, then the result is “1”,
otherwise, the result is “0”.
0 1
0
0 1
1 1 1
XOR
The logical XOR (exclusive OR) operation compares 2 bits and if exactly one of them is a “1”, then
the result is “1”, otherwise the result is “0”.
0 1
0
0 1
1 1 0
NOT
The logical NOT operation simply changes the value of a single bit. If it is a “1”, the result is
“0”, if it is a “0”, the result is “1”. This operation is carried out on a single bit.
0 1
1 0
163
