www.austin-hughes.com UM-IGM-03-Q314V1 P.65
The EC-300M master box can manage the connected EC-300 slave box in a single daisy-chain up to
16 levels via SNMP v2c ( Simple Network Management Protocol).
Only EC-300M master box can support SNMP.
( I ).
Accessing MIB Files
Use the World Wide Web (WWW) to download the SNMP MIB file at this URL:
http://www.austin-hughes.com/support/utilities/infraguard/IGM-MIB.mib
( II ). Enabling SNMP Support
The following procedure summarizes how to enable the EC-300M master box for SNMP support.
Step 1
. Connect the EC-300M master box to a computer.
( Please refer to < 4.2 > Master IP Configuration )
Step 2
. Open the Internet Explorer ( I.E. ) version 8.0 or above
Step 3
. Enter the configured IP address of EC-300M master box into the I.E. address bar.
Default IP address is “ 192.168.0.1 “
Step 4
. Enter “ Login name “ & “ Password “. Default login name & password are “ 00000000 “
Part VIII. SNMP
