Austin Hughes IGM-03 - Manual (Page 29)

www.austin-hughes.com UM-IGM-03-Q314V1
P.24
463
43.5
5 6 7
- Unit CFM Status LED
- Unit CFM Setting
1
2 4
-
Individual fan status
- Individual fan On /
Off buttons
3
- Buttons for Alarm
Temp. Setting
- Temp. LED display
- DIP switch for
daisy chain level setting
5
6
7
TEMP LINK OUT
- Temp. port bundled w/ a temp. sensor
- Daisy chain
L I N K
port for connecting to the
out port of the last level fan unit
- Daisy chain
O U T
port for connecting to the
link port of the next level fan unit
Model : RF-1.3
1U Fan Tray with 3 fans
< 3.2 > Fan Unit
